| Bearing Type | : | Sleeve |
| Enclosure Type | : | OAO |
| Frame Size | : | 48 |
| Frequency Rating | : | 50/60 Hz |
| HP (Decimal) | : | 0.25 |
| HP (Fraction) | : | 1/4 |
| Insulation Class | : | B |
| Motor Type | : | PSC Blower |
| NEMA Dimensions (In) | : | 5.6875 x 8.125 |
| New Long Description-500 | : | MOTOR, AC, DIRECT DRIVE BLOWER, 230V AC, 0.25HP, 1075RPM SPEED, 60HZ FREQUENCY, 1 PHASE, CCW ROTATION, 48 FRAME, PSC TECHNOLOGY, 3 SPEEDS, OAO ENCLOSURE, B INSULATION CLASS, AUTOMATIC PROTECTOR, THERMAL PROTECTOR, SLEEVE BEARING, 0.5IN SHAFT DIAMETER, 5.6875IN DIAMETER, 8.125IN HEIGHT NEMA DIMENSIONS, MEETS CSA, UL |
| New Short Description- 150 | : | MOTOR,AC,DIRECT DRIVE BLOWER,230V AC,0.25HP,1075RPM,60HZ,1 PH,CCW ROTATION,48 FR,PSC TECH,3 SPEED,OAO ENCL,B INSUL,AUTOMATIC PROTECTOR,SLEEVE BRG |
| Number of Phase | : | 1 |
| Number of Speeds | : | 3 |
| Protector Type | : | Automatic |
| Rotation | : | CCW |
| Shaft Diameter (In) | : | 0.5 |
| Speed (RPM) | : | 928 to 1,200 |
| Standards | : | CSA,UL |
| Suggested Capacitor | : | 7.5 MFD/370V AC |
| Technology | : | PSC |
| Thermal Protector | : | True |
| Voltage (VAC) | : | 208 to 230 |
